KiCad tutorial 12: Simulation of CMOS inverter circuit using KiCad Global Library
8:09
YouTubeCircuit Generator
KiCad tutorial 12: Simulation of CMOS inverter circuit using KiCad Global Library
In this KiCad tutorial we will simulate a CMOS inverter circuit. We will use the AOS transistor model which we will add in the KiCad library. For any digital circuits CMOS inverter forms a basic building block. In this KiCad tutorial we will also perform the DC analysis of CMOS inverter using AOS PMOS and NMOS devices from KiCad global library ...
1.8K viewsAug 22, 2021
